Semi auto l shrink packing machine

Features

L heat shrink packaging machineBy FQL - 450 - a half since bar sealer and BSD4525A shrink machine of two parts, automatic bar sealer products to shrinkage furnace, shrink packaging. bar sealer conveying speed and bar time is adjustable.shrink machineThe inner loop carrying wind technology, not only shorten the heating time, and shrinkage effect is better. Also can according to product size matching other model machine. Suitable for packing box, toys, electronic products, etc.
product feature ：
Resistance to high temperature alloy“L”type Seal cutting knife，sealing and tidy not craze, coking, don't smoke.
Coated with teflon non-stick layer dragon knife, sealing and cutting mucous membrane.
The inner loop double furnace, heat is more uniform.
Imported electric parts configuration, use more stable.

Parameter

model	L sealing and cutting machine （FQL-450A）	model	shrink machine BSD4525A
Power supply	220v/50-60HZ	Power supply	220-240V/50-60H
Converyor speed	0-15m/min	Heater power	10KW
Seal aize	600*450mm	Converyor speed	0-15m/min
Shink prouduct size	L520*W410mm	Tunnel size	1000m
Converyor loading	25kg Max	Converyor loading	15kg
Machine size	1450*670*1000mm	Machine size	130*720*880mm
Machine weight	110kg	Machine weight	120kg
Shrink film	POF.PVC.PP	Shrink film	POF.PVC.PP

Other

shrinkage furnace size can be customized
optional shrinkage furnace in circular of direct heat
